TMX 8 MYi

Turning Centers

Powerful productivity in alive tooling turning center.

Facts and figures

Travels

X-Axis (mm) 203
Y-Axis (mm) +/- 55
Z-Axis (mm) 560
W-Axis (mm) 640

Machine Capacity

Turning diameter max. (mm) 336
Max. swing over bed (mm) 508

Spindle

Spindle Speed max. (1/min) 4.500
Spindle Torque (S6 / S1) (Nm) 239 / 164
Chuck diameter (mm) 200
Spindle Power (S6 / S1) (kW) 25 / 17,2
Draw Tube Diameter (mm) 64,5

Live Tools

Spindle Speed max. (rpm) 4.000
Spindle Power (kW) 5,4
Spindle Torque max. (Nm) 23


Feedrates

Rapid traverse X/Y/Z/W-Axis (m/min) 24 / 30 / 30 / 12

Turret

Type VDI 40 / DIN 1809
Stations 12
Boring Bar Diameter max. (mm) 40
Tool Shank Width (mm) 25

Further details

Floor space required (mm) doors open, incl. control unit and chip conveyor 5.510 x 3.485 x 2552
Machine weight (kg) 7.500

Information may change without notice. Optimum machine performance is reliant upon installation conditions at the facility, such as power supply, air supply, and ambient air conditions.
